Items |
200A
Branch |
600A
Branch |
Rated
Voltage
|
15kV |
15kV |
Loop
Resistance |
≤200μΩ |
≤40μΩ |
AC
Withstand Voltage |
39kV/5min |
39kV/5min |
Lightning Impulse
Withstand Voltage
|
95kV |
95kV |
Rated
Current
|
200A |
600A |
Thermal
Short-circuit |
35kA, 3s |
27kA, 4s |
Dynamic
Short-circuit |
10kA, 0.2s |
50kA, 0.3s |
Partial
Discharge |
15kV, ≤5pC |
15kV, ≤5pC |
|
|
■ Fully
insulated and sealed
■ Dustproof,
fireproof, anti-corrosive and maintenance-free.
Be applied in any bad environment
■ Meet
the IEEE 386 and IEC 60502 standards
■
Short-circuit fault indicator helps you
detect faults
quickly
■ Meet
multiple grounding requirements
■ Small
volume, compact structure, easy installation
and reliable operation
|
